The display delivers a strong and clearer picture while providing higher-resolution images up to 1024 ¡Ñ 768

Based on different working environments or surveillance needs, a combination of different security products can be looped together for a more integrated solution

With this function, the displays won't be affected by the impedance issue when being loovped together



Quick 0.8 seconds switching time to ensure the rapid succession of various input signals

For complete global signal support, the SX-15 provides signal system compatibility for NTSC, PAL and SECAM

  Features
1024 ¡Ñ 768 XGA resolution
Supports color and B/W picture
NTSC/PAL/SECAM scan system compatible
Selectable signal source: Analog, Digital and Auto Composite System
PC compatible

Triple coated on both sides, the NeoV Crystal Optic Filter offers anti-glare, anti-reflective properties, while delivering greater color definition. Mount the LCD display on the wall to save even more valuable desktop space. Mount the LCD display on the wall to save even more valuable desktop space. Automatically adjustment screens settings for optimal image, without changing settings manually. Protects the LCD panel from potential damage caused by repeated touching of the surface.
NeoV Optical Glass Video In Metal Casing Auto-Adjustment LCD Panel Protection
On-Screen Display (OSD) makes adjusting the display settings quick and convenient. On-Screen Display (OSD) makes adjusting the display settings quick and convenient. Advanced gas-spring suspension guarantees smooth stable operation, and flexibility of use. Mount the LCD display on the wall to save even more valuable desktop space.
Digital OSD Kensington Security Slot Arm Mount Wall Mount Kit

SX-15
  Panel Size 15.0" (381mm)
  Brightness 400cd/m2 (Typical)
  Contrast Ratio 500:1 (Typical)
  Viewing Angle (H/V) 140o / 125o (Typical)
  Display Resolution XGA 1024 x 768
  Input Signal Analog, Digital, Auto Composite System
  Input Connector Analog, Digital, BNC Security
  Output Connector BNC Connector
  Response Time 8ms (GTG)
  Net Dimension 380 x 359 x 155mm
    (15.0" x 14.1" x 6.1")
  Net Weight 4.8Kg (10.6lbs)

All specifications are subject to change without prior notice
